OLED (Oganic Light-Emitting Diode): Organic light-emitting diodes, also known as organic electro-laser displays, OLED display technology has self-luminescent properties, using a thin organic material coating and glass substrates, which glow when a current passes through them, and the display area is 128 × 64 dot matrix, each dot can glow by itself, so it has no backlight. It can display Chinese characters, ASCII, patterns, etc. It looks very beautiful and has a very high contrast.
Availability:

1.3 inch OLED LCD display

Product introduction

OLED (Oganic Light-Emitting Diode): Organic light-emitting diodes, also known as organic electro-laser displays, OLED display technology has self-luminescent properties, using a thin organic material coating and glass substrates, which glow when a current passes through them, and the display area is 128 × 64 dot matrix, each dot can glow by itself, so it has no backlight. It can display Chinese characters, ASCII, patterns, etc. It looks very beautiful and has a very high contrast. Moreover, the OLED display has a wide viewing angle, uniform picture quality, fast response, stable image, high brightness, high resolution, and a 1.3 inch large screen to make the display clearer.


Product parameters

Parameter type Characteristics
Specification 36×36mm
Positioning aperture Two 3mm  two 3*6mm
Working voltage 3.3-5V
Interface 4P
Line sequence G V SCL SDA
Display Size 1.3 inch
resolving power 128*64
Driver chip SSD1306
Viewing angle direction Greater than 160°
working temperature -40℃~70℃
communication mode IIC
Device address 0×3C


Single chip microcomputer wiring

Maker:Temperature and humidity detection device
