The combination of waterproof DS18B20 temperature sensor and Aduino can be used in many places, such as soil temperature detection, temperature control of hot water tank, etc. However, the waterproof DS18B20 temperature sensor needs a pull-up resistance to be used, so the DS18B20 converter board we have designed will come in handy. The DS18B20 converter digital port adds a pull-up resistance, which directly connects the waterproof DS18B20 temperature sensor to Arduino for use.
| Parameter type | Characteristics |
|---|---|
| Specification | 12×31mm |
| Pipe Packaging | Waterproof, moisture-resistant |
| Control signal | Digital signal |
| Working voltage | 3.3-5V |
| Interface | 3P |
| Line sequence | G V A |
| Stainless steel lead | 375mm |
| Pipe length | 6 * 50mm |
| Stainless steel lead | DS18B20 temperature sensor (each pin of the chip is separated by a heat-shrinkable tube to prevent short circuit and internal seal) |
| Temperature Sensing Range | -55~125℃ (Lead can only withstand temperature around 85℃) |
The combination of waterproof DS18B20 temperature sensor and Aduino can be used in many places, such as soil temperature detection, temperature control of hot water tank, etc. However, the waterproof DS18B20 temperature sensor needs a pull-up resistance to be used, so the DS18B20 converter board we have designed will come in handy. The DS18B20 converter digital port adds a pull-up resistance, which directly connects the waterproof DS18B20 temperature sensor to Arduino for use.
| Parameter type | Characteristics |
|---|---|
| Specification | 12×31mm |
| Pipe Packaging | Waterproof, moisture-resistant |
| Control signal | Digital signal |
| Working voltage | 3.3-5V |
| Interface | 3P |
| Line sequence | G V A |
| Stainless steel lead | 375mm |
| Pipe length | 6 * 50mm |
| Stainless steel lead | DS18B20 temperature sensor (each pin of the chip is separated by a heat-shrinkable tube to prevent short circuit and internal seal) |
| Temperature Sensing Range | -55~125℃ (Lead can only withstand temperature around 85℃) |
