Human infrared sensor

Share to:
It can detect the infrared emitted by moving people or animals and output switch signals. It can be applied to various occasions that need to detect moving human bodies. When someone enters the sensing range, the high level will be input, and when someone leaves the sensing range, the high level will be closed automatically and the low level will be output.
Availability:

Human infrared sensor

Product introduction

It can detect the infrared emitted by moving people or animals and output switch signals. It can be applied to various occasions that need to detect moving human bodies. When someone enters the sensing range, the high level will be input, and when someone leaves the sensing range, the high level will be closed automatically and the low level will be output. The product has high sensitivity, strong reliability, low power consumption and low voltage working mode. It is widely used in moving human body detection, occupancy detection, infrared anti-theft system, and other automatic induction electrical equipment, especially the automatic control products powered by dry battery.


Product parameters

Parameter type Characteristics
Specification 22×30mm
Positioning aperture 3mm
Control signal Digital signal
Working voltage 3.3-5V
Interface 3P
Line sequence G V D
Output delay time 2.3 ~ 3 seconds
temperature range -20℃~85℃


Single chip microcomputer wiring

接线方式

Maker:Human body induction lamp device

装置
