6.0 laser module, laser head diameter 6.0 mm, positive and negative terminal, operating voltage 3.0v-5v, can only see a faint red line if there is fog or other media, but normally a red dot, the tube is made of copper.
Availability:

Laser head module

Product introduction

6.0 laser module, laser head diameter 6.0 mm, positive and negative terminal, operating voltage 3.0v-5v, can only see a faint red line if there is fog or other media, but normally a red dot, the tube is made of copper. Mainly used for laser toys, light-emitting gyroscopes, lighters, various levels, earth wire meters, etc.

Special attention: Do not shine into the human eye.


Product parameters

Parameter type Characteristics
Specification 22×30mm
Positioning aperture 3mm
Control signal Digital signal
Working voltage 3.3-5V
Interface 3P
Line sequence G V D
Laser Wavelength 650nm
Transmission power 150mW
Output power <5mW
Power supply voltage 5VDC
Working Current 40mA
Characteristic Spotted light spot, continuous output

Single chip microcomputer wiring

接线方式

Maker:Smart Gate Lock

装置
