The vibration motor module is a small high-level and low-level vibration motor. It is mainly equipped with a micro vibration motor. There is an eccentric wheel on the Mada shaft. When the motor rotates, the center particle of the eccentric wheel is not on the rotation center of the motor, making the motor constantly out of balance. Vibration is caused by inertia.
Availability:

Vibrating motor

Product introduction

The vibration motor module is a small high-level and low-level vibration motor. It is mainly equipped with a micro vibration motor. There is an eccentric wheel on the Mada shaft. When the motor rotates, the center particle of the eccentric wheel is not on the rotation center of the motor, making the motor constantly out of balance. Vibration is caused by inertia.


Product parameters

Parameter type Characteristics
Specification 22×30mm
Positioning aperture 3mm
Control signal

Digital signal

Working voltage 3.3-5V
Interface 3P
Line sequence G V D
Rated current 60 Ma Max
Starting current

90 Ma Max

Rated speed Minimum 9000 rpm
Insulation resistance 10Mohm

Single chip microcomputer wiring

接线方式(600
